技术参数
TECHNICAL PARAMETERS>>>
|
型号 |
Model |
JL-QX-A90 |
|
圆钢直径 |
Round steel diameter |
≤90mm |
|
传送方式 |
Transmission method |
串杆式 |
|
喷头数量 |
Number of nozzles |
≈18个 |
|
材 质 |
Material |
304不锈钢(喷塑) |
|
通 道 |
Channel |
宽130mm/可调节式 |
|
补水控制 |
Water replenishment control |
自动补水 |
|
低压电器 |
Low voltage electrical apparatus |
法国施耐德 |
|
变频器 |
Frequency converter |
德国西门子 |
|
离心泵品牌 |
Centrifugal pump brand |
中国南泵 |
|
离心泵规格 |
Centrifugal pump specifications |
热水型/耐高温/单泵 |
|
离心泵型号 |
Centrifugal pump model |
CDLF10-21FSWSR |
|
输入电源 |
Input power supply |
AC380V 50/60HZ |
|
离心泵功率 |
Centrifugal pump power |
7.5kw |
|
电机功率 |
Motor power |
0.75kw |
|
压力范围 |
Pressure range |
≈1.6-2.0MPa |
|
环境温度 |
Ambient temperature |
0 ～ 50℃ |
|
外形尺寸 |
Dimension |
1606*1650*1720mm |
